Unmanned Supermarket System Solution
Background Management System
- Incoming stocktaking
- Item warehousing (item pairing RFID)
- Commodity settlement and delivery
- Information push
- Door monitoring
- Fund settlement
- Daily operation and maintenance (inventory, sales)
Payment System
- Commodity self-identification
- Face payment
- QR code payment
Security Management System
- Face detection
- Site security
- Commodity anti-theft
- Sound and light alert
Business Functions
- Perimeter security video
- Sound and light reminder when exiting
- Shopping guide
- Face recognition for access
- Automated object identification using RFID
- Personalized recommended products
- Anti-theft AB door
- Mobile payment
Cloud Service Capability
- Multiple users
- Rules engine
- User management
- Inventory management
- Character management
- Sales management
- Permission management
- Report generation
- Security certification
- Alarm management
- Data storage
- Third-party API
Smart Factory System Solutions
Data collection and edge processing of factory equipment are realized through wireless communication modules and edge computing smart devices.
Production Parameter Collection
- Multi-channel transmitter data (meter, current, voltage)
- Multiple digital data
Field Device Status Indication
- Normal operation
- Abnormal operation warning
Production Line Equipment Linkage
- Node identification
- Gateway networking
- Cloud display control
Business Functions
- Device Security Management
- Production line status control
- Interoperable ERP system
- Real-time production data presentation
- Historical data crystal report
- Smart Equipment operation and maintenance
- Sound and color warning indication
- Team productivity ranking
Edge Gateway Capability
- Rules engine
- Device management
- Data filtering
- Safety certificate
- Log management
- Alarm management
- Data storage
- Multi-protocol device access
Cloud Service Capability
- Multi-user
- Authority management
- Data display
- Device management
- Safety certificate
- Third-party API
- User management
- Data storage
- Smart alert
- Role management
- Rules engine
- One-click O&M
Intelligent Settlement System Solution
The informatization solution based on Internet of Things technology integrates a series of intelligent and automated service equipment to assist restaurants, supermarkets and other commercial places to optimize services.
This solution can be applied to restaurants, supermarkets and other commercial places with customized settlement desk. It features quick payment (automatically identify products and automatic pricing) and self-service (face payment, Alipay, WeChat Pay, one-card payment). This helps to reduce labor costs and improve consumption efficiency.
Business Functions
- Tableware management
- Inventory management
- Parameter settings
- Meal management
- Staff management
- Order list
- Menu management
- Organizational management
- Sales statistics
Cloud Service Capability
- Multi-tenancy
- Device management
- User management
- Role management
- Authority management
- Safety certificate
- Data storage
- Rules engine
- Data display
- Third-party API
- Warning and maintenance
Smart Grid Equipment Online Monitoring Platform
The smart grid equipment online monitoring platform is based on a new generation of service-oriented architecture (SOA). Through a unified data model, flexible calculation and analysis models, polymorphic alarm identification and processing strategies, combined with the rapid intelligent access technology of equipment, it can be quickly constructed. The monitoring and control system of various equipment in the smart grid is one of the most important supports for improving the level of lean and intensive management of equipment.
Microgrid Solutions
In the context of world energy shortage and increasing environmental protection requirements, distributed power generation and energy supply have become an important development direction to achieve energy saving and emission reduction. Using this solution, the effective management of distributed power generation and the gradient utilization of energy can be realized, the protection, control, and scheduling problems of the microgrid can be solved, the security of the power grid can be improved, and the construction of a smart grid with clean, effective and sustainable energy supply can be realized.
Testing Business - Core Technical Services
After 8 years of experience, innovation, and progress, Hopefun testing business has accumulated affluent product experience and can provide testing services including complete machines, chips, mobile applications, and other products. We also assist customer products with various cooperation models, advocate and adhere to the concept of `"technical innovation, professional service"`, and provide first-class and professional software testing services.
Internet Application Business - Core Technical Services
With end-to-end multi-faceted application development capabilities, Hopefun has been heavily involved in popular technical fields such as Android, iOS and HTML5, especially in framework optimization and 3D special effects with outstanding technical advantages in the industry.
Chip Business - Core Technical Services
Hopefun deeply cultivates in Field Programmable Gate Arrays (FPGA) debugging, System-on-a-Chip (SOC) driver camera, audio and video, GPU performance effect tuning and other core chip areas, chip-level Android/Linux/Zephyr and other OS porting core technical capabilities, complete chip debugging tool development capabilities, and one-stop Turnkey Solutions which has reached in-depth cooperation with other chip companies.
Terminal Business - Core Technical Capabilities
HopePro has multi-platform, multi-system, and multi-device development capabilities based on Qualcomm, MTK, Spreadtrap, and other platforms. Also for mobile phone systems such as Android, Tizen, and Firefox, develop systems, application APIs, and communication protocols for mobile phones, tablets, TV, IoT, and other device services, through big big core technical capabilities to provide customers with ROM upgrades and customized services for operators in North America, Japan, South Korea, Europe, and China.
Face Detection Tablet
| 8 Inch Tablet | ||
|---|---|---|
| Material | Metal | |
| Connection method | WIFI | |
| Processor | Snapdragon 660/8 core | |
| Display chip | Adreno512 | |
| Storage | 64GB | |
| RAM | 4GB | |
| Resolution | 1920 x 1200dpi | |
| Screen size | 8 inches | |
| Screen ratio | 16:10 | |
| Front camera | 500W | |
| Size | 200.2mm x 120.3mm x 7.8mm | |
| Thickness | 7.8mm - 9mm | |
| Net weight | 342.5g | |
Checkout Counter
| Check Out Counter | ||
|---|---|---|
| Shell material | Carbon steel plate | |
| Display | Touch display | |
| Panel material | Tempered glass | |
| Operating voltage | AC 220V ± 10% | |
| Operating temperature | -10℃ to 50℃ | |
| Total power | 60W | |
| Radio frequency | High frequency | |
Dual Gigabit LAN Gateway (Edge Gateway)
| UTX-3117 | ||
|---|---|---|
| Processor system | ||
| CPU | Intel Apollo Lake E3900 & N Series Processors | |
| L2 Storage | 2MB | |
| BIOS | AMI EFI 16 Mbit | |
| RAM | ||
| Technology | Dual channel DDR3L 1867MHz, up to 8GB | |
| Pin | Two 204-pin SO-DIMMs | |
| Graphic Card | ||
| Chip | Intel Apollo Lake E3900 Series SoCs Intel Apollo Lake N Series SoCs | |
| Interface | HDMI: 1, Maximum resolution 3840 x 2160 @ 30Hz DPI.2: 1, Maximum resolution 4096 x 2160 @ 60Hz | |
| The internet | ||
| Local area network | Support dual network card 10/100/1000Mbps LAN Card 1: Intel I210AT LAN Card 2: Realtek RTL8111G | |
| I/O interface | ||
| Serial Port | 5V/12V RS-232 * 1 Full duplex RS-422/485, 1 | |
| USBA | USB 3.0 * 2 | |
| SATA | SATA interface, 1, support SSD | |
| TPM | Built-in Infineon SLB9665 chip, support TPM 2.0 | |
| Extension ports | ||
| Mini PCIe | SubIG module supporting half-size Mini-PCIe (ie: Zigbee) *1,3G/LTE module with SIM card holder supporting full-size Mini-PCIe, 1 Support M.2 electronic key Wi-Fi module, 1 | |
| Hard disk | ||
| 2.5" SSD | SATA II SSD bay 1 | |
| mSATA | H/S miniPFIE coexistence slot, 1 | |
| Operating system | ||
| Microsoft | Windows 10, Yocto, Wind River Pulsar Linux and WiSE | |
| Windows | PaaS | |
| Power requirements | ||
| Input voltage | 12 - 24V | |
| Power adapter | AC to DC, DC12-24V | |
| Power consumption | Typical: 12V, 0.35 (A), 4.2W Maximum: 12V, 0.61 (A), 7.32W | |
| Mechanical properties | ||
| Material | Aluminium | |
| Installation method | Support VESA/DIN rail/wall mount (optional) | |
| Dimensions (WxHxD) | Bottom frame: 128 (L) x 152 (W) x 37mm (H) Motherboard: 123.3 x 129mm | |
| Environment and certification | ||
| Operating temperature | E3900 Series - -20 - 60°C N Series - 0-55°C | |
| Storage temperature | -40 - 85°C | |
| Relative humidity | 95% @ 40°C (non-condensing) | |
| EMC | CE/FCC Class B | |
| Security certificate | CB, UL, CCC, BSMI | |
Low Frequency Half Duplex LoRa Terminal
| Working environment | ||
|---|---|---|
| Working temperature | -40°C ~ +85°C | |
| Working humidity | 5% - 95% RH (non-condensing) | |
| Storage temperature | -40°C ~ +125°C | |
| Storage humidity | 1% - 95% RH (non-condensing) | |
Product Parameters
| Software and hardware parameters | ||
|---|---|---|
| Security mechanism | 128-bit data encryption | |
| LoRa communication rate | 0.268 ~ 21.8 kps | |
| Letter of agreement | Private protocol | |
| Configuration method | PC setting software, serial AT command | |
| Operating voltage | 5V ~ 36V | |
| Working current | Transmit current 115mA @5V Standby current 45mA @5V | |
| Size | 86.0 x 102.2 x 25.0mm (LxWxH) | |
| SIM/USIM | Standard 6-pin SIM card interface, 3V/1.8V SIM card | |
| Wireless Parameters | ||
|---|---|---|
| Wireless standards | LoRa | |
| Frequency range | 398 - 525MHz | |
| Transmitting power | 10dBm - 20dBm | |
| Receiver sensitivity | 138.5dBm @0.268kbps | |
| Antenna | SMA Antenna Holder (Outer Screw Inner Hole) | |
| Transmission distance | 2000m (test conditions: sunny, open, maximum power, antenna, gain 5dBi, height greater than 2m, 0.488k, default channel) | |
| Serial Port | ||
|---|---|---|
| Number of ports | RS232*1, RS485*1 | |
| Standard | RS-232 DB9 male, RS-485 (A+, B-) | |
| Data bits | 8bit | |
| Stop bit | 1,2 | |
| Check digit | None, Even, Odd | |
| Baud rate | 1200/2400/4800/9600/19200/38400/57600/115200 | |
| Cache | RX:200byte, TX: 200byte | |
Low Power Wide Area Network LoRa Concentrator
| Work environment | ||
|---|---|---|
| Working temperature | -20°C ~ +70°C | |
| Working humidity | 5% - 95% RH (non-condensing) | |
| Storage temperature | -40°C ~ +125°C | |
| Storage humidity | 1% - 95% RH (non-condensing) | |
| Software and hardware parameters | ||
|---|---|---|
| Security mechanism | 128-bit data encryption | |
| LoRa communication rate | 0.268 ~ 21.8kbps | |
| Letter of agreement | Private protocol | |
| Configuration method | Web configuration | |
| Operating voltage | DC5-36V (standard 12V/1A) | |
| Power consumption | 5V/0.6A 12V/0.3A 36V/0.07A | |
| Size | 149.99 x 135.15 x 33.2mm (WxHxH) | |
| SIM/USIM card | Standard 5-pin SIM card interface, 3V/1.8V SIM card | |
| Wireless parameters - LoRa | ||
|---|---|---|
| Wireless standards | LoRa | |
| Frequency range | 398 - 525MHz | |
| Transmitting power | Maximum 20dBM | |
| Receiver sensitivity | 138.5dBm | |
| Antenna | Default suction cup antenna SMA antenna base (outer screw inner hole) | |
| Transmission | Distance 2000m (test conditions: clear, open, maximum power, antenna gain 5dBi, height 2m, 0.488k air speed string, default channel) | |
| Coverage distance | 120m (open area) | |
| Wireless parameters 2/3/4G (-42) | ||
|---|---|---|
| Standard | TD-LTE/FDD-LTE/WCDMA/TD-SCDMA/GSM/EDGE | |
| Band standard | ||
| TD-LTE | Band 38/39/40/41 | |
| FDD-LTE | Band 1/3 | |
| WCDMA | Band 1/8 | |
| TD-SCDMA | Band 34/39 | |
| GSM/GPRS/EDGE | Band 3/8 | |
| Technical specifications | ||
| TD-LTE | 3GPP RO CAT4 downlink 150Mbps, uplink 50Mbps | |
| FDD-LTE | 3GPP R9 CAT4 downlink 150Mbps, uplink 50Mbps | |
| WCDMA | HSPA+ Downlink 21Mbps Uplink 5.76 Mbps | |
| TD-SCDMA | 3GPP R9 CAT4 downlink 2.8Mbps, uplink 2.2Mbps | |
| GSM/GPRS/EDGE | MAX: downlink 384kbps, uplink 128kbps | |
T5200 Android Dual Screen Cashier Terminal
| Motherboard | ||
|---|---|---|
| CPU | Qualcomm Snapdragon 8-core processor | |
| RAM | 2GB RAM | |
| Memory | 16GB ROM | |
| Operating system | Android 7.1 | |
| Memory expansion | MicroSD support (TF), up to 64GB | |
| SIM | Support, standard large card | |
| Home screen side button | Power button x 1, Volume up button x 1, Volume down button x 1 | |
| Button | Paper feed button x 1, paper cavity button x 1 | |
| Micro-USB | Debugging, switch HUB, disconnected by default | |
| Speaker | 2W speaker .90dB | |
| RTC clock | With button battery | |
| Main display | ||
| Size | 15.6 inches | |
| Resolution | 1920 x 1080 Pixel (standard) | |
| Touch screen | Multi-touch capacitive screen | |
| Monitor | ||
|---|---|---|
| Size | 11.6 inch (standard), 15.6 inch (optional) | |
| Resolution | 11.6 inches (1366 x 768 pixel), 15.6 inches (1920 x 1080 pixel) | |
| Touch screen | None (standard), multi-touch capacitive screen (optional) | |
| VO Port | ||
|---|---|---|
| Serial | 1 x RS232 (RJ11) | |
| USB | 4 x USB2.0 (TYPE A double layer) | |
| LAN network port | 1 x RJ-45 (10/100M) | |
| Cash drawer interface | 1 x RJ12 | |
| Audio port | 1 x Audio 3.5mm | |
| Built-in equipment | ||
|---|---|---|
| GSM | 2G frequency band B2/B3/B5/B8 (optional) | |
| UMTS | 3G frequency band B1/B2/B5/B8 (optional) | |
| TDS | 3G band RR4/R30 (France) | |
| TDD-LTE | 4G frequency band B38/B39/B40/B41 (optional) | |
| FDD-LTE | 4G frequency band B1/B3 (optional) | |
| WiFi | Support IEEE 802.11 a/b/g/n wireless protocol 2.4G (standard), 5G (optional) | |
| Bluetooth | Support Bluetooth 2.1/3.0/4.0, support BLE, support ibeacon | |
| NFC | External NFC module (optional) | |
| Printer | ||
|---|---|---|
| Printer width | 72mm | |
| Paper roll specifications | 79.5±0.5mm (width) x 80mm (diameter) | |
| Cutter | support half cut | |
| Printing speed | 220mm/s | |
| Resolution | 203 dpi | |
| Life | the longest printing is 150km, and the paper cutting is 1.5 million times | |
| Other | ||
|---|---|---|
| Power supply | 24V power supply | |
| Colour | customizable | |
| Size | 400 x 270 x 420 (LxWxH) | |
| HBS-T6 induction | ||
| Induction | ||
|---|---|---|
| Mating size | L780mm x W450mm x H60mm | |
| Reading area | L420mm x W320mm | |
| Payment method | IC card, cash, Alipay, WeChat | |
| Working environment | -10-50 degrees | |
| Relative humidity | 5% - 95% | |
| Operating voltage | DC12V | |
| Read and write time | TMAX < 100ms (normal card) | |
| Card reading frequency | 13.56 MHz | |
| Supported card types | Support ISO14443 protocol Mifare One card, CPU card | |
| Transmission rate | 10M/100M adaptive | |
